Grid Switches

Grid switches let you create your own custom switch combination on a single plate, rather than being limited to a standard fixed layout. A grid switch is made up of three parts: the yoke or frame, the individual switch modules that fit into it, and the front plate that sits over the top.

How do grid switches work?

You choose the plate you want, then select the modules you need — light switches, dimmers, or other accessories — in the order you'd like them to appear on the plate. The yoke holds the modules in place behind the front plate, which is then secured with fixing screws. The mounting screws on the yoke are positioned to fit a standard wall box or pattress box.

What can I combine on a grid switch plate?

Grid switches are commonly used to combine intermediate switches with two-way (or one-way) switches, giving you a non-standard combination that wouldn't be available as a pre-configured plate. Our grid plates currently go up to 4-gang, giving you flexibility to combine up to four modules on one plate.

Need help choosing a grid switch configuration?

If you need a hand working out the right combination for your circuit, call us on 02920 004 887 and our customer service team will talk you through it, or use the chat box on our site.

Frequently Asked Questions

What is a grid switch?

A grid switch lets you combine your own selection of switch modules on a single plate, made up of a yoke, the switch modules, and a front plate. It's used where a standard, pre-configured plate doesn't offer the combination you need.

How many modules can I fit on a grid switch plate?

Our grid plates currently go up to 4-gang, allowing up to four modules on one plate.

Can I mix different types of switch on one grid plate?

Yes — a common use is combining intermediate switches with two-way switches on the same plate, which wouldn't be available as a standard fixed-configuration product.

Related guides: what does gang mean? and what is a grid plate?
